| Overall packer dimensions (LxWxH), mm: 2800 x 1150 x 2090 |
| Maximum stack travel speed, m/min: 6 |
| Maximum stack dimensions (WxHxD) mm: 1300 x 1200 x 12000 |
| Consumed electrical power, kW: 1.5. szh. air 4 atm. - 100l/min. |
| The width of film coils is 500 mm. The inner diameter of the spool is 76 mm. (Otherwise by agreement) |
| Quantity of carriages with a film - 2 pieces. |
| Spool rotation speed - 10 rpm. |
| Automatic gripping of band ends and its cuts at the end of the cycle |
| Distance from the floor to the pallet feeding plane - 450 mm |
There is no need for a pit to accommodate the packer.
